Model: G01-CWF01
Power Input 5~24 VDC
Current consume max.1A Reverse / Surge protection
Communication Ethernet or Wi-Fi 2.4 GHz
Certification CE/FCC

GPM Support Vibration Sensor with Wi-Fi or Ethernet. They could deliver the vibration sensing data to iDMS software in the computer . The iDMS using the vibration data to diagnosis the health of equipment & show alert.

Model: G01-SR-MVR01
G Value Scope :±2g /±4g /±8g /±16g
Axes Qty: 3 (Gx , Gy ,Gz)
Sample Rate:5KHz
IP Level: IPX7
Certification CE/FCC

Micro Vibration Sensor mount on the key device of motion equipment.
To collect the sensing raw data, it could provide to health diagnosis.

API Type：DLL Library
Environment：Net Framework in computer
Communication：Ethernet or Wi-Fi 2.4GHz
API Output data：
　Raw data
　F.F.T. in frequency
　Vibration Energy
　RMS (Root Mean Square)
　P2P (Peak to Peak)
API Error Return：Error Code return

Easy way to software integrate with GPM API , it could connect to sensor controller.
API Support data output: raw data (time domain) & F.F.T. data (frequency domain), Vibration Energy/RMS/P2P.
User fast develop the software & function with GPM API & their domain Knowhow.
